UN-TFA1628C-10MP
| Objectif FA compact série Taurus ( 10 MP) |
|||||
| Modèle |
UN-TFA1628C -10MP |
||||
| Distance focale |
16 millimètres |
|
|||
| Ouverture |
F2.8-16 |
||||
| Format d'image |
2/3 ″ |
||||
| Monter |
C |
||||
|
Angle de champ P x H x V (°) |
|
2/3 ″ |
1/2 ″ |
1/3" |
|
| D |
37.9 _ |
28 . 1 ° |
21,2 ° |
||
| H |
3 0 . 7 ° |
2 2 . 6 ° |
17,0 ° |
||
| V |
23 . 3 ° |
1 7 . 1 ° |
12,8 ° |
||
| Distorsion optique |
0,29 %@y= 5,5 mm |
0. 1 5%@y=4. 0 mm |
0,0 8 % @ y= 3,0 mm |
||
| MODÈLE |
0,15m~ ∞ |
||||
| Dimension |
Φ 29 * 41,50 mm |
||||
| Bride BFL |
17,526 mm |
||||
| Distance focale arrière _ _ |
8,63 millimètres |
||||
| Opération |
Iris manuel |
||||
| Mise au point manuelle |
|||||
| Longueur d'onde de conception |
420-1000nm |
||||
| Fil de filtre |
M27xP0,5 |
||||
 |
|||||
verre de qualité optique
Line Scan Lens UN-ALS60056L-8K
For inspection of lithium battery separators and coated copper & aluminum foils, high-end printing and anti-counterfeit packaging, precision testing of PCBs and 3C electronics, surface defect detection of metal sheets and coils, flat panel display & glass defect inspection, and dimension measurement of various rolled materials.
· Developed for 64mm big frame sensor
· Low distortion
· Compatible for 2K, 4K, 8K line scan camera
· Excellent optical performance, uniform imaging of center and edge
Product information: Custom designs are available upon request.
