Line Scan Lens UN-ALS14604L16K-0.5X
For high-end PCB AOI micro-inspection, Mini/Micro LED panel pixel defect detection, photovoltaic silicon wafer EL hidden crack inspection, narrow high-temperature metal strip flaw detection, luxury anti-counterfeit printing texture inspection, electronic ceramic substrate microscopic testing, UAV high-precision aerial survey mapping and ultra-precise online dimensional measurement of micro electronic components.
· Developed for 82mm big frame sensor
· Low distortion
· Compatible for 16K line scan camera
· Excellent optical performance, uniform imaging of center and edge
Product information: Custom designs are available upon request.
prisme rhomboïde de haute précision
UN-TFA3520X-12MP
| Objectif FA au format 4/3 ″ série Taurus ( 12 MP) |
|||||
| Modèle |
UN-TFA3520X-12MP |
||||
| Distance focale |
35 mm |
|
|||
| Ouverture |
F2.0 -F22 |
||||
| Format d'image |
4/3 ″ (23mm) |
||||
| Monter |
C |
||||
|
Angle de champ P x H x V (°) |
|
4/3 ″ |
1 " |
1/2" |
|
| D |
36,8 ° |
26,0 ° |
13,2 ° |
||
| H |
29,7 ° |
20,8 ° |
10,6 ° |
||
| V |
22,5 ° |
15,8 ° |
7,9 ° |
||
| Distorsion optique |
-0,52%@ y = 11,5 mm |
-0,42%@ y = 8,0 mm |
-0,12%@ y = 4,0 mm |
||
| MODÈLE |
0,2 m |
||||
| Dimension |
Φ 48,5 * 64,3 mm |
||||
| Distance focale arrière |
18mm |
||||
| Longueur d'onde de conception |
420 ~ 1000 nm |
||||
| Opération |
Iris manuel |
||||
| Mise au point manuelle |
|||||
| Fil de filtre |
M46 × P0,75 |
||||
| Poids _ |
207 g |
||||
| Température de travail |
-20 ℃ ～+60 ℃ |
||||
| |
|||||
lentille de tige micro tailles
