UN-LFA1236C-10MP
UN-AT16014S-12MP
Product Features:
· Excellent edge sharpness and uniform illumination
· Designed to resist strong light interference, adaptable to complex lighting conditions
· Ultra-high resolution,accurately capture license plates and facial details
Product information: Custom designs are available upon request.
UN-AT25014C-12MP
Product Features:
· Excellent edge sharpness and uniform illumination
· Designed to resist strong light interference, adaptable to complex lighting conditions
· Ultra-high resolution,accurately capture license plates and facial details
Product information: Custom designs are available upon request.
UN-AT35014S-12MP
Product Features:
· Excellent edge sharpness and uniform illumination
· Designed to resist strong light interference, adaptable to complex lighting conditions
· Ultra-high resolution,accurately capture license plates and facial details
Product information: Custom designs are available upon request.
UN-AT50014S-12MP
Product Features:
· Excellent edge sharpness and uniform illumination
· Designed to resist strong light interference, adaptable to complex lighting conditions
· Ultra-high resolution,accurately capture license plates and facial details
Product information: Custom designs are available upon request.
lentilles cylindriques rectangulaires plan-convexes
UN-TFA1620X-12MP
| Objectif FA au format 4/3 ″ série Taurus ( 12 MP) |
|||||
| Modèle |
UN-TFA1620X-12MP |
||||
| Distance focale |
16 millimètres |
|
|||
| Ouverture |
F2.0 -F22 |
||||
| Format d'image |
4/3 ″ (23mm) |
||||
| Monter |
C |
||||
|
Angle de champ P x H x V (°) |
|
4/3 ″ |
1 " |
1/2" |
|
| D |
73,0 ° |
54,2 ° |
28,3 ° |
||
| H |
61,0 ° |
44,3 ° |
22,7 ° |
||
| V |
47 . 3 ° |
33 . 6 ° |
17,1 ° |
||
| Distorsion optique |
-1,93%@ y=11,5 mm |
-1,82%@ y = 8,0 mm |
-0,55%@ y = 4,0 mm |
||
| MODÈLE |
0,1 m |
||||
| Dimension |
Φ 60,2 * 85,9 mm |
||||
| Distance focale arrière |
21mm |
||||
| Longueur d'onde de conception |
420 ~ 1000 nm |
||||
| Opération |
Iris manuel |
||||
| Mise au point manuelle |
|||||
| Fil de filtre |
M58.0×P0.75 |
||||
| Poids _ |
339g _ |
||||
| Température de travail |
-20 ℃ ～+60 ℃ |
||||
| |
|||||
UN-TFA3518C
produit Caractéristiques:
1. Compatible pour 2 / 3 '' Capteur de format
2. Ultra-compact conception
3. distorsion ultra faible
4. Éclairage relatif élevé
5. performance élevée
6. Fourniture avec mise au point et verrouillage de l'iris vis.
produit Information: Designs personnalisés sont disponibles sur demande.
Télécharger le Fiche technique de UN-TFA3518C
